USB1.1 To Fiber Extender Only for Keyboard and Mouse

  • Description
  • Technical data
  • Make an inquiry

    Product Overview

    This USB to Fiber Extender Only for Keyboard and Mouse is a professional HID signal dedicated optical extension device. It is designed exclusively for USB keyboard and mouse signal transmission, not applicable for USB flash drives, industrial cameras, printers, USB audio and other high-speed/bulk data devices. By converting USB control signals to optical fiber signals, it achieves long-distance, anti-interference and zero-latency remote keyboard and mouse control, which is widely used in server room remote management, industrial control center monitoring, and professional AV system remote operation.

     Core Features

    • HID Dedicated Design: Only supports USB keyboard and mouse signals, optimized for low-latency human interface control, no signal delay or cursor drift
    • Powerful Anti-interference Performance: Fiber optic galvanic isolation, completely eliminates ground loop noise, EMI and RFI interference in complex industrial environments
    • Long Distance Transmission: Supports singlemode LC fiber transmission, stable long-range control far beyond traditional USB cable distance limits
    • True Plug & Play: No driver, no software, no complex configuration, automatic signal identification and connection
    • Ultra-low Latency: Hardware real-time signal processing, ensures sensitive keyboard response and smooth mouse movement
    • Industrial Stability: Metal alloy housing, good heat dissipation, support 24/7 continuous working
    • Wide Compatibility: Compatible with all standard USB wired keyboards and mice, support Windows, Linux, Mac OS systems

     Application Scenarios

    • Data center server remote keyboard & mouse control
    • Industrial workshop remote monitoring and operation room control
    • Security monitoring center long-distance desktop control
    • Broadcasting and professional equipment remote operation
    • Isolated electromagnetic environment remote HID control
    Specification
    Optical
    Wavelength:
    1310/1550nm
    Output Power :
    -14~ -8dBm /-5~0dBm
    Optic fiber :
    50/125u multimode, 62.5/125u multimode, 9/125u single mode
    Rx sensitivity :
    -30dBm
    Optical connector :
    FC /ST /SC /LC (optional)
    Distance :
    0~250Meter(SM)
    USB Signal
    USB protocol:
    USB1.1
    Use:
    Keyboard and Mouse Signal through Fiber Transmission
    Number of  Transmitter Channel :
    2 * USB1.1 Port for keyboard and Mouse
    Number of  Receiver Channel :
    1 * USB1.1 Port for keyboard and Mouse

    Electrical & Mechanical

    Input Power Requirements :
    DC 5V~12V
    Power Adapter :
    AC 90V~240V
    Power Consumption :
    < 3W
    Stand-Alone Dimensions :
    104mm × 104mm × 28mm
    Shipping Weight :
    (include Transmitter & Receiver ) 0.75Kg
    Material:
    Aluminium Alloy
    Color:
    Black

    Environmental

    Operation Temperature :
    -20°C ~ +70°C
    Storage Temperature :
    -40°C ~ +85°C
    Relative Humidity:
    0% ~ 95% (non-condensing)
    MTBF:
    >100,000 hours
