Parameters
|
Single-mode
|
Multimode
|
||
|
Connector A:
|
Dual E-2000™(SC, FC, ST, LC, MTRJ Optional)
|
|||
|
Connector B:
|
Duplex SC (Dual E-2000™, FC, ST, LC, MTRJ Optional)
|
|||
|
Polishing Type:
|
PC
|
UPC
|
APC
|
PC
|
|
Insertion Loss (dB):
|
≤0.2
|
≤0.25
|
||
|
Return Loss (dB):
|
≥45
|
≥50
|
≥60
|
N/A
|
|
Repeatability (dB):
|
IL≤0.2 RL≤5
|
IL≤0.1
|
||
|
Vibration (dB):
|
IL≤0.2 RL≤5
|
IL≤0.2 dB
|
||
|
Exchangeability (dB):
|
IL≤0.2 RL≤5
|
IL≤0.2 dB
|
||
|
Tensile Strength (kg):
|
10
|
|||
|
Vibration (dB):
|
≤0.2
|
|||
|
Durability:
|
≤0.2 typical change, 1000 matings
|
|||
|
Ferrule Material:
|
Zirconia Ceramic
|
|||
|
Jacket Material:
|
PVC, LSZH, OFNR
|
|||
|
Cable Color (Single Mode: OS1 & OS2):
|
Yellow
|
|||
|
Jacket Colour (Multimode: OM1 & OM2):
|
Orange
|
|||
|
Jacket Colour (Multimode: OM3 & OM4):
|
Aqua
|
|||
|
Cable Length (m):
|
1, 2, 5, 10, 20, 30, 50,100 or customized
|
|||
|
Cable Diameter (mm):
|
Ø0.9, Ø2.0, Ø3.0
|
|||
|
Operation Temperature (℃):
|
-20 ~ +70℃
|
|||
|
Storage Temperature (℃):
|
-40 ~ +85℃
|
|||
 |
