Description
8-ch 3G/HD-SDl Fiber Optical Multiplexer (Or 4-ch BlDl 3G/HD-SDl Fiber Optical multiplexer) is an ideal and economicsolution for broadcasting or OB-Van. lt receives 8 channels 3G/HD/SD-SDl electrical input, perfectly converts electrical SDilsignal to single mode optic SDl signal. it supports transmission image of SDTV (143-540Mbps), HDTV (1.485Gbps) and HDTV (3Gbps, 1080p60).
Both transmiter and receiver provide equalizing and reclocking at input unit in order to re-construct the signal for consistentquality. Besides, with HZT advanced fiber technology, SDl can easily pass pathological pattern to prove its completetransmission.
Feature
● 8 Channel HD-SDl High density digital audio/video fiber transmission
● Compatible with any Serial signal on coax up to 3.0 Gbps SDl Internal optics for 1 fiber transport through CWDM Multiplexing independent
●Full rate 3.0 GHz channels on separate CWDM Lasers
● Handle all Pathological patterns
● SD/HD-SDl input auto indentification, support three datarate 270Mbits -1.48Gbits -2.97Gbits,support 1080P 3Gbps HD-SDI format
● Support SMPTE-292M、SMPTE-259M、SMPTE-424M
● 10Km on single Mode Fiber transmission
● 1270-1610nm CWDM wavelengths.
