Description:
HZT-SDI-12G-3VV41E-SM001 is designed and produced by HZT technology and which has an ideal solution for broadcasting event production applications. It can transmits 3-ch 12G-SDI digital video signal+1-ch Return 12G-SDI digital video +1 port 10/100/1000M Isolated Ethernet over Single LC Fiber Converter. It supports transmission of UHDTV/4K/8K/HDTV/SDTV SDI signal.
Both transmitter and receiver provide equalizing and re-clocking at input unit in order to re-construct the signal for consistent quality. Besides, with HZT technology advanced fiber technology, SDI can easily pass pathological pattern to prove its complete transmission.
Features
● 3 input 1 output 12G-SDI High density digital audio/video fiber transmission
● 1 ports 10/100/1000M Ethernet transmission
● Handle all Pathological patterns
● 12G-SDI: Supports SMPTE 2082-1, SMPTE 2081-1, SMPTE 424M, SMPTE 292M, and SMPTE 259M (C) Serial Digital Video Standards, Supports 270Mbit/s - 1.48Gbit/s - 3Gbit/s, 5.94Gbit/s, and 11.88Gbit/s Serial Data Rate
● Support 0-10Km on single Mode Fiber transmission
● 1470~1610nm CWDM wavelengths optional.
Application
● 12G/3G/HD-SDI monitor system;
● Live on optical fiber transmission;
● TV remote studio;
● The military and public security command and control
● Event production;
