| Optical： | Wavelength: | 1310nm / 1550nm / CWDM | |
| Output Power: | -6~-1dBm | ||
| Rx sensitivity: | <-18dBm | ||
| Transmission Distance: | Remote power 100W，SMPTE hybrid cable 200+meter | ||
| Optical connector: | Lemo SMPTE 304 / Neutrik OpticalCON DUO , Camera end can be rotated 90 degrees | ||
| SDI input /output: | Signal format: | SMPTE ST-2082, ST-2081, 424M, 344M, 292M, 259M, DVB-ASI, | |
| Data rate: | 270Mbit/s, 1.48Gbit/s, 2.97Gbit/s, 5.94Gbit/s, 11.88Gbit/s | ||
| Cable Equalization: | Automatic cable EQ (Belden 1694A cable) 75 m at 11.88 Gbps (4Kp60 UHD) 120 m at 5.94 Gbps (UHD) 200 m at 2.97 Gbps (FHD) 280 m at 1.485 Gbps (HD) 600 m at 270 Mbps (SD) |
||
| SDI interface: | BNC 75 Ohm | ||
| SDI Number: | Camera Adapter | Base Station | |
| 1-CH 12G-SDI Video Input+Loop, 1-CH 12G-SDI Video Output |
1-CH 12G-SDI Video Input, 1-CH 12G-SDI Video Output | ||
| Genlock /BB/TC: | Input/output impedance: | BNC 75Ω (unbalance) | |
| Input/output voltage: | 1.0Vp-p | ||
| Differential Gain: | < ±1.5% | ||
| Differential Phase: | < ±1% | ||
| SNR: | >60dB | ||
| BB/TC Number: | Camera Adapter | Base Station | |
| 1-CH BB/TC output | 1-CH BB/TC input, 1-CH BB/TC Loop-out | ||
| Intercom: | Camera Adapter | Base Station: | |
| Interface: | 4-pin XLR(Male) / 5-pin XLR(Female)/ 3.5mm headset jack | 3-pin XLR Female/Male: Party line audio for Clearcom / Altairaudio / Granitesound’s Intercom main station ,or Line level balanced audio input and output DB9(Female): Line level unbalanced audio input and output, | |
| Microphone: | Mic inputs with mute and pre-amps | None | |
| Headphone: | with volume up or down | None | |
| Tally: | Camera Adaptor | Base Station | |
| Interface: | 4-pin or 3pin mini XLR | DB9(Male) | |
| Input/Output: | Dry Contact Closure or wet LED+/- (Output) | Dry Contact Closure or TTL (Input) | |
| LED Indicator: | On: short or LED on Off: open or LED off | On: short to GND or TTL low, Off: open or TTL high | |
| Remote： | Camera Adapter | Base Station | |
| Interface: | Sony 8-pin interface | Sony 8-pin interface | |
| Data: | RS422 /RS232/RS485 | RS422 /RS232/RS485 | |
| PGM: | Camera Adapter | Base Station | |
| Interface: | 4-pin XLR(Male) /5pin XLR(Female)/ 3.5mm headset jack | 3-pin XLR Female: Line level balanced audio input, | |
| Headphone: | with volume up or down | None | |
| Physical: | Camera Adaptor | Base Station | |
| Input power: | DC 11~19V | AC90~240V | |
| Power consumption: | <12W | <12W | |
| Net weight: | 1kg | 3kg | |
| Appearance size: | 188mm*116mm*45mm | Standard 1U Rack Chassis | |
| Work Temp: | -25°C to 55°C | ||
| Storage Temp: | -40°C to 85°C | ||
| Humidity: | 0 ~ 95% (non-condensing) | ||
 |
